Built-In Refrigeration 11
subzero.com/specs
Overlay Panels
ICBBI-30U / ICBBI-36U
H
H
H
W
*Panel height may be increased by 13 mm to hide upper main
frame. For more information, refer to the built-in panel config-
urator at subzero.com/trade/panels.
Grille panel dimensions listed are for a standard 2134 mm
finished height. For a 2108 mm finished height, subtract 25
mm from grille panel height dimensions. For a 2235 mm
finished height, add 102 mm to height dimensions. A 2108
mm or 2235 mm panel grille must be ordered to accept a
2108 mm or 2235 mm custom panel. Width dimensions do
not vary.
Model ICBBI-30U
REFRIGERATOR W H
Overlay Panel 762 mm 1273 mm
Spacer Panel 740 mm 1253 mm
Backer Panel 756 mm 1268 mm
FREEZER W H
Overlay Panel 762 mm 483 mm
Spacer Panel 740 mm 459 mm
Backer Panel 756 mm 475 mm
GRILLE W H
Overlay Panel 762 mm 235 mm*
Spacer Panel 740 mm 211 mm
Backer Panel 756 mm 227 mm
Model ICBBI-36U
REFRIGERATOR W H
Overlay Panel 914 mm 1273 mm
Spacer Panel 892 mm 1253 mm
Backer Panel 908 mm 1268 mm
FREEZER W H
Overlay Panel 914 mm 483 mm
Spacer Panel 892 mm 459 mm
Backer Panel 908 mm 475 mm
GRILLE W H
Overlay Panel 914 mm 235 mm*
Spacer Panel 892 mm 211 mm
Backer Panel 908 mm 227 mm
