Function: Compressor1 LP Fault Digital Input Sensing
Delay. (Normal)
Example: If Ln1 is set to 5 seconds, once the Compressor1
is ON, if the LP Input is unhealthy for continuous 5
seconds, controller will trip the Compressor on LP Fault.
Note:
• This parameter is considered only if L01 is enabled
and CS not equal to C2.
Function: To set reset mode for Compressor1 output, on
Compressor1 LP Fault Digital Input.
If this parameter is set to,
= Auto Reset Option for LP Fault.
= Manual Reset Option for LP Fault after
L41 retrials in 1 Hour.
Example:
If user has set the parameter to following:
= LP Fault will get cleared automatically once
the Input becomes healthy.
= If this parameter is set to and L41
parameter is set to 5 then if the
Compressor gets tripped on LP fault for 5
times in 1 hour, controller will go into
Manual Reset and user has to reset the
fault through RST key by pressing for 2
Seconds. Fault will get cleared only if the
Input has become healthy.
Note:
• This parameter is considered only if L01 is enabled
and CS is not equal to C2.
Function: No of retrials of Compressor1 LP Fault Digital
Input when Manual Reset is selected.
Example: If this parameter is set to 5, Compressor will go
into Manual Reset if the LP fault occurs 5 times in an Hour.
Note:
• The Fault counts will get cleared in every hour.
• This parameter is considered only if L01 is enabled
and CS is not equal to C2.
