Non-turbo
models
The
cruise
control
set
indicator
light
illuminates
when
the
ignition
switch
is
turned
to
the
“
ON
”
position
and
turns
off
after
approximately
3
seconds.
The
light
illuminates
when
vehicle
speed
has
been
set.
Starting
and
operating
7-53
272
274
