No. Parts name Function
(a)
Cockpit Control Unit
䠄CCU䠅
䠄Cockpit Gen.1.0
7-inch dual display audio䠅
- Controls the Gen. 4.0 7-inch dual display audio and plays the audio of audio sources
such as AM/FM radio, SiriusXM radio and USB audio.
- Recognizes passenger voice commands input from the microphone to execute
operations.
- Outputs the voice signals from each audio source to the speakers.
(b)
Center information display䠄CID䠅
䠄Cockpit Gen.1.0
7-inch dual display audio䠅
- Displays the operation screen and status information screen of the selected audio
source.
- Equipped with a built-in Bluetooth module, which enables playback of audio files and
the use of hands-free functions when connected with a compatible device.
(c)
Embedded Antenna
(Glass printed antenna)
(AM/FM Radio)
- The printed antenna located in the rear windshield receives AM/FM radio broadcast
waves.
(d)
Antenna Amplifier
Amplifies the AM/FM radio broadcast waves received by the radio antenna and
outputs the amplified waves to the head unit.
(e)
Roof Antenna
(SiriusXM radio)
The fin type antenna located on the roof receives SiriusXM radio broadcast waves and
outputs the waves to the cockpit control unit.
(f)
Microphone
Located in the map light, the microphone collects the sound of the passenger's voice
when using the voice recognition function or hands-free function.
(g)
Steering switch
Used to operate volume adjustment or switch between modes, and sends audio
operation signals such as station selection to the cockpit control unit.
(h)
External Input Terminal
- One AUX terminal and two USB terminals are provided as input terminals for external
devices.
- When a portable audio player is connected to the AUX terminal, the voice signal is
output to the cockpit control unit.
- When USB memory or a device such as an iPod or iPhone is connected to the USB
terminal, USB communication is performed with the cockpit control unit. The device
connected to the USB terminal can also be charged.
(i)
Front Door Speaker
Outputs the voice signals input from the cockpit control unit.
(j)
Rear Door Speaker
