No. Parts name Function
(a)
Cockpit Control Unit
䠄CCU䠅
䠄Cockpit Gen.1.0.
11.6-inch display audio/
11.6-inch display navigation䠅
- Controls the Gen. 4.0 11.6-inch display audio or 11.6-inch display navigation and plays
the audio of audio sources such as AM/FM radio, SiriusXM radio and USB audio.
- Recognizes passenger voice commands input from the microphone to execute
operations.
- Outputs the voice signals from each audio source to the speakers.
- Equipped with a navigation computer, which calculates the current location based on
data such as information received from the navigation antenna and plots the current
location screen.
(b)
Center information display
䠄CID䠅
䠄Cockpit Gen.1.0.
11.6-inch display audio/
11.6-inch display navigation䠅
- Displays the operation screen and status information screen of the selected audio
source.
- Equipped with a built-in Bluetooth module, which enables playback of audio files and
the use of hands-free functions when connected with a compatible device.
- Displays the navigation screen plotted by the cockpit control unit.
(c)
Embedded Antenna
(Glass printed antenna)
(AM/FM Radio)
- The printed antenna located in the rear windshield receives AM/FM radio broadcast
waves.
(d)
Antenna Amplifier
Amplifies the AM/FM radio broadcast waves received by the radio antenna and
outputs the amplified waves to the head unit.
(e)
Roof Antenna
(SiriusXM radio)
The fin type antenna located on the roof receives SiriusXM radio broadcast waves and
outputs the waves to the cockpit control unit.
(f)
GPS Antenna
Receives orbital signals from a satellite orbiting the Earth at an altitude of
approximately 20,000 km and sends the signals to the navigation computer in the
cockpit control unit.
(g)
Antenna Amplifier
Amplifies the AM/FM radio broadcast waves received by the radio antenna and
outputs the amplified waves to the head unit.
(h)
Steering switch
Used to operate volume adjustment or switch between modes, and sends audio
operation signals such as station selection to the cockpit control unit.
(i)
External Input Terminal
- One AUX terminal and two USB terminals are provided as input terminals for external
devices.
- When a portable audio player is connected to the AUX terminal, the voice signal is
output to the cockpit control unit.
- When USB memory or a device such as an iPod or iPhone is connected to the USB
terminal, USB communication is performed with the cockpit control unit. The device
connected to the USB terminal can also be charged.
(j)
Instrument Panel side speaker
Outputs the voice signals input from the cockpit control unit
(k)
Front Door Speaker
(l)
Rear Door Speaker
