ABS-24
ABS (DIAGNOSTICS)
LIST OF DIAGNOSTICS TROUBLE CODE
11.List of Diagnostics Trouble Code
A: LIST
1. WITHOUT SUBARU SELECT MONITOR
Tr o u b l e
code
Contents of diagnosis Index No.
11
Start code
• Trouble code is shown after start code.
• Only start code is shown in normal condition.
—
21
Abnormal ABS sensor
(Open circuit or input
voltage too high)
Front right ABS sensor
<Ref. to ABS-39, TROUBLE CODE 21 — ABNORMAL ABS SEN-
SOR (OPEN CIRCUIT OR INPUT VOLTAGE TOO HIGH) (FRONT
RH) —, Diagnostics Chart with Diagnosis Connector.>
23 Front left ABS sensor
<Ref. to ABS-39, TROUBLE CODE 23 — ABNORMAL ABS SEN-
SOR (OPEN CIRCUIT OR INPUT VOLTAGE TOO HIGH) (FRONT
LH) —, Diagnostics Chart with Diagnosis Connector.>
25 Rear right ABS sensor
<Ref. to ABS-39, TROUBLE CODE 25 — ABNORMAL ABS SEN-
SOR (OPEN CIRCUIT OR INPUT VOLTAGE TOO HIGH) (REAR
RH) —, Diagnostics Chart with Diagnosis Connector.>
27 Rear left ABS sensor
<Ref. to ABS-40, TROUBLE CODE 27 — ABNORMAL ABS SEN-
SOR (OPEN CIRCUIT OR INPUT VOLTAGE TOO HIGH) (REAR
LH) —, Diagnostics Chart with Diagnosis Connector.>
22
Abnormal ABS sensor
(Abnormal ABS sen-
sor signal)
Front right ABS sensor
<Ref. to ABS-46, TROUBLE CODE 22 — ABNORMAL ABS SEN-
SOR (FRONT RH) —, Diagnostics Chart with Diagnosis Connec-
tor.>
24 Front left ABS sensor
<Ref. to ABS-46, TROUBLE CODE 24 — ABNORMAL ABS SEN-
SOR (FRONT LH) —, Diagnostics Chart with Diagnosis Connector.>
26 Rear right ABS sensor
<Ref. to ABS-46, TROUBLE CODE 26 — ABNORMAL ABS SEN-
SOR (REAR RH) —, Diagnostics Chart with Diagnosis Connector.>
28 Rear left ABS sensor
<Ref. to ABS-48, TROUBLE CODE 28 — ABNORMAL ABS SEN-
SOR (REAR LH) —, Diagnostics Chart with Diagnosis Connector.>
29 Any one of four
<Ref. to ABS-54, TROUBLE CODE 29 — ABNORMAL ABS SEN-
SOR SIGNAL (ANY ONE OF FOUR) —, Diagnostics Chart with
Diagnosis Connector.>
