Installation Information
INSTALLATION SPECIFICATIONS
Over-and-Under Models —
Framed, Overlay (non-flush inset) and
Stainless Steel
A
Model BI-30U 29
1
/ 2 " (749)
Model BI-30UG 29
1
/ 2 " (749)
Model BI-36U 35
1
/ 2 " (902)
INSTALLATION SPECIFICATIONS
Over-and-Under Models —
Flush Inset Application
AB
Model BI-30U 29
1
/ 2 " (749) 32" (813)
Model BI-30UG 29
1
/ 2 " (749) 32" (813)
Model BI-36U 35
1
/ 2 " (902) 38" (965)
Dimensions in parentheses are in
millimeters unless otherwise specified.
75
1
/2"
(1918)
7"
(178)
6"
(152)
E
LOCATE
ELECTRICAL
WITHIN
SHADED AREA
18"
(457)
W
LOCATE WATER SUPPLY
WITHIN SHADED AREA
6"
(152)
FRONT VIEWSIDE VIEW
83
3
/4"
(2127)
OPENING
HEIGHT
A
OPENING WIDTH
3" (76)
24" (610)
OPENING
DEPTH
1
/2"
(13)
18" (457) *
6"
(152)
24" (610)
OPENING
DEPTH
SHUT-OFF
VALVE
OUTLINE OF
FRAMED, OVERLAY
OR STAINLESS
STEEL MODEL
TOP VIEW
*ANTI-TIP BRACKET MUST NOT
INTERFERE
WITH WATER LINE.
REFER TO INSTALLATION
INSTRUCTIONS FOR COMPLETE
DETAILS.
EXTEND WATER LINE APPROX
36" (914) FROM BACK WALL.
WATER LINE
75
1
/2"
(1918)
7"
(178)
6"
(152)
E
LOCATE
ELECTRICAL
WITHIN
SHADED AREA
1
/2"
(13)
18" (457) *
6"
(152)
24" (610)
OPENING
DEPTH
26
3
/16"
(665)
FLUSH INSET
DEPTH
SHUT-OFF
VALVE
OUTLINE
OF FLUSH INSET
APPLICATION WITH
3
/4" (19) PANEL
18"
(457)
W
LOCATE WATER SUPPLY
WITHIN SHADED AREA
6"
(152)
FRONT VIEWSIDE VIEW
TOP VIEW
83
3
/4"
(2127)
OPENING
HEIGHT
84"
(2134)
FLUSH
INSET
HEIGHT
1
/4" (6)
2
3
/16"
(56) **
3" (76)
A
OPENING WIDTH
B
FLUSH INSET WIDTH
1
1
/4"
(32)
1
1
/4"
(32)
2
3
/16"
(56) **
24" (610)
OPENING
DEPTH
26
3
/16" (665)
FLUSH INSET
DEPTH
*ANTI-TIP BRACKET MUST NOT
INTERFERE
WITH WATER LINE.
REFER TO INSTALLATION
INSTRUCTIONS FOR COMPLETE
DETAILS.
**ASSUMES
3
/4" (19) PANEL
THICKNESS.
EXTEND WATER LINE APPROX
36" (914) FROM BACK WALL.
WATER LINE
1
/4"
(6)
1
1
/4"
(32)
FLUSH INSET
DETAIL
2
3
/16"
(56)
24" (610)
OPENING
DEPTH
Model BI-36UFD 35
1
/ 2 " (902)
Model BI-36UG 35
1
/ 2 " (902)
Model BI-36UFD 35
1
/ 2 " (902) 38" (965)
Model BI-36UG 35
1
/ 2 " (902) 38" (965)
Model BI-42UFD 41
1
/ 2 " (1054)
Dimensions are for finished rough openings.
Model BI-42UFD 41
1
/ 2 " (1054) 44" (1118)
Dimensions are for finished rough openings.
