SECTION 3 ES-6 USER MANUAL
45
3.15 ID,PIPING AND INSTRUMENTATION DIAGRAM—STANDARD AND WYE-DELTA
NOTES:
1. PART NUMBERS ARE FOR REFERENCE ONLY. REFER TO
BILL OF MATERIAL AND OR FACE OF ORDER FOR ACTUAL
PARTS.
2. SECTION BETWEEN LETTERED POINTS ARE TO BE
REPLACED WITH CORRESPONDING OPTION PICTURED
BELOW, AS REQUIRED BY FACE OF ORDER.
3. CONTROL/MOISTURE DRAIN LINES ARE 1/4’’ TUBING
EXCEPT AS NOTED.
4. OPTIONAL HEAT TRACE IS APPLIED ONLY TO CONTROL
AND MOISTURE DRAIN LINES AND USED ONLY WITH
STAINLESS STEEL TUBING. REFER TO FACE OF ORDER
FOR HEAT TRACE REQUIREMENTS.
5. PART VARIES BY MODEL.
COSTUMER CONNECTIONS
OPEN MACHINE 1/2’’ NPT
ENCLOSED MACHINE 1/2’’ NPT
WITH TANK 1 1/4’’ NPT
WITH TANK AND DRYER 3/4’’ NPT
ITEM
NO.
DESCRIPTION PART NO. QTY NOTE
1 filter, air heavy duty es-6 02250111-679 1
2 valve, air intake sub-assy 606448 1
3 motor various 1
4 valve, solenoid n.o. 500psi 02250125-655 1
5 cooler, oil aftercooler es-6 250026-066 1
6 pressure gauge 250005-185 1
7 pressure switch 250025-299 1
8 valve minimum pressure check 604243 1
9 valve pressure relief 200# 250006-938 1
10 sight glass 250025-420 1
11 temperature gauge 43307 1
12 temperature switch 250025-300 1
13 thermostat valve various 1
14 valve, check 1/2” fpt, 1/2” mpt 15#psi 02250042-940 1
15 fluid filter 250026-982 1
16 gear spray - 1
17 gear box - 1
18 male blocking - 1
19 female blocking - 1
20 compressor - 1
21 element separator air/oil e6e 250025-264 1
22 tube separator oil return 250025-865 1
23 rotor inlet end bearings - 1
24 male injection - 1
25 female injection - 1
26 valve, pressure regulator 250017-280 1
27 valve, ball 1/4” 250028-454 1
28 switch, pressure rg 6.5 to 8,5 nc 250032-763 1
29 tank, receiver 80 gal 02250170-199 1 5
30 valve pressure relief 200# 250006-938 1
31 valve, ball 1/4”npt 47115 1
32 filter, sch-40n 02250153-051 1 5
33 dryer, srs-50 02250169-525 1 5
34 valve, ball 1/2” npt 47117 1
35 valve, ball 3/4” npt 47118 2
