13.2 Exploded diagrams
13.2.1 Components of the exploded diagrams
1
Alu drying module
16
Coil for condensate drain solenoid valve
1.1 Insulation material
17
Air dryer control
2
Refrigerant pressure switch LPS
21
Sullimax drain
3
Safety temperature switch TS
22
Main switch
4
Refrigerant pressure switch HPS
5
Refrigerant fan pressure switch PV
51
Front panel
6
Compressor
52
Back plate
7
Hot-gas bypass valve
53
Right sidewall
8
Condenser
54
Left sidewall
9
Condenser fan
55
Cover
9.1 Motor
56
Base plate
9.2 Blade
57
Upper plate
9.3 Grid
58
Carrier support
10
Filter dryer
59
Support bracket
11
Capillary tube
60
Control panel
12
T1 temperature probe (dew point)
61
Electric connecting plug
13
Condensate drain service valve
62
Electric cabinet
14
Condensate drain strainer
65
Condenser filter
15
Condensate drain solenoid valve
81
Adhesive label flow chart
