1. BEFORE PROCEEDING
WARNING: Read all the instructions completely before proceeding.SUMERAIN recommends calling a professional
if you are uncertain about installing this product!, this product should be installed in accordance with all
local and state plumbing and building codes.
2. SHUT OFF WATER SUPPLY
Locate water supply inlets and shut off the water supply valves. These are usually found near the water meter. if you are
replacing an existing unit, remove the old unit and clean the mounting surface thoroughly.
3. CHECKING THE CONTENTS OF THE BOX
Upon opening the box, check to ensure that all the following items are included.
If any of these items are missing, please contact SUMERAIN consumer service by email to: supports@sumerain.com
CODE ITEM NAME QTY CODE ITEM NAME QTY
3218001 Concealed Box 1 PCS 3218002 Rough-in valve 1 PCS
3218003 Sleeve 1 PCS 3218004 Φ40 cartridge 1 PCS
3218005 Bonnet nut 1 PCS 3218006 Escutcheon 1 PCS
3218007 Flange 1 PCS 3218008 Handle(lever) 1 PCS
3218009 Diverter cartridge 1 PCS 3218010 Diverter sleeve 1 PCS
3218011 Diverter knob 1 PCS 3218012 Shower arm 1 PCS
3218013 Shower arm flange 1 PCS 3218014 Shower head 1 PCS
3218015 Wall elbow holder assembly 1 PCS 3218016 Handheld shower 1 PCS
3218017 Shower hose 1 PCS 3218018 Set screw 2 PCS
3218019 Allen wrench 2.8mm 1 PCS 3218020 Screw cover 1 PCS
3218021 Mounting screw 4 PCS 3218022 Anchor 4 PCS
