Sun joe SB601E - Blade Installation and Replacement; Removing the Blade; Installing the SharperBlade

6
4) Place the Shield over the blade shaft and snap into place
(Figure 3).
5) Now the diameter of the protection area is 9 inches (Figure
4).
6) Ultimately you can remove the ower guard from the
motor cover. This will allow you maximum use of the
SharperBlade.
NOTE: Be careful when operating the machine while steel
ower guard is removed.
Installing or Changing Blade
1) Remove screw knob (Figure 5).
2) Remove the washer (Figure 6).
3) Assemble the SharperBlade to the Electric Trimmer/Edger
(Figure 7).
screw knob
washer
Sharper Blade
Figure 3
Figure 6
Figure 7
Figure 5
Figure 4
