7752C Rev. D 6
PARTS LIST
MODEL 7752C (Rev. D)
CAPACITY: 1-1/2 TON
TRANSMISSION JACK
1 RS7752D01 Wheel Assembly/each (incl. #1,2,3) 4
2 Washer
6
3
Nut 6
4 Frame Board Assy. 1
5 Bolt
2
6
Shaft 1
7 Washer
1
8 Rod Link 2
9 Washer
2
10 Saddle Seat 1
11
Shaft 1
12 Washer
4
13
Bracket 1
14
Nut 2
15
Shaft 1
16
Pin 2
17 ** Bolt
9
18
Handwheel 2
19 RS7752D19 Adjustment Rod Assembly/each (incl. #16-19) 2
20 ** Nut 3
21 RS7752D21 Shaft 1
22 RS7752D22 Retaining Ring/each 6
23 ** Nut 2
24 ** Bearing 4
25 ** Nut 2
26 RS7752D26 3" Shaft 1
27 RS7752D27 5.5" Shaft 1
28 Grease Fitting 1
29 Lift Arm Assembly 1
30
Pin 2
31
Shaft 2
32 Rod Link 2
33 Washer 2
34 Rod Link 1
35
Pin 1
1-0 RS7752DHU Complete Hydraulic Unit 1
1-1 Washer 1
1-2 Washer 2
1-3 * O-ring 1
1-4 Piston Rod 1
1-5 Piston ring 1
1-6 * Sealing washer 1
1-7 * O-ring 1
1-8 Washer 1
1-9 Washer 1
1-10
Body 1
1-11 * Oil filler plug 1
1-12 Washer 2
1-13 Bolt 2
1-14 Bolt 1
1-15 * Copper washer 1
1-16 Valve 1
1-17 * Steel ball 6 2
1-18 * O-ring 2
1-19 RS7752D119
Release Valve Assembly (incl. 1-19 to 1-21)
1
1-20 Pin 1
1-21 Release Knob 1
1-22 Screw 1
1-23 * Steel ball 4 1
1-24 Ball seat 1
1-25 * Spring 1
1-26 Screw 1
1-27 Sealing washer 1
1-28 Screw 1
1-29 * Spring 1
1-30 * Steel ball 9 1
1-31 * Spring 1
1-32 * Copper washer 1
1-33 Screw 1
1-34 * Copper washer 1
1-35 Washer 3
1-36 Bracket 1
1-37 Pin 1
1-38 * Y-ring 1
1-39 * O-ring 1
1-40 Cylinder Pump 1
1-41 Pump cylinder 1
1-42 * Dustproof plug 1
1-43 Washer 2
1-44 Pin 2
1-45 Handle 1
1-46 Handle Sleeve 1
3-1 *** Bolt
2
3-2 *** Washer 2
3-3 *** Lock Washer 2
3-4 RS7752D34 Chain/each
2
3-5 *** Nut 2
3-6 *** Bolt
4
3-7 RS7752D37 Bracket/each 2
3-8 Saddle Plate 1
3-9 *** Washer 4
3-10 *** Wing Nut 4
3-11 *** Nut 2
3-12 *** Washer 2
3-13 RS7752D313 Bracket/each 2
3-14 *** Wing Nut 2
3-15 *** Adapter Bolt
2
3-16 *** Chain Hook 2
3-17 Bolt 2
3-18 Board 1
RS7752DLK Product Label Kit (not shown) 1
*
Available in seal kit, RS7752DSK
** Available in saddle bearing kit, RS7752DSBK (incl. #17 (7),
#20 (3), #23 (2),
#24 (4), #25 (2).
*** Available in bolt kit, RS7752DBK
Only index numbers identified by part number are a
vailable separately
.
Index Part
No. No. Description Qty.
Index Part
No. No. Description Qty.
