7793B REV. F 8 rev. 2/24/20

1 * Scraper Seal 1

2 * O-Ring 1

3 * U-Ring 1

4 Steel Ball 1

5 * Screw 1

6 * Oil Cup 1

7 Secondary Ram 1

8 Circlip 1

9 * Scraper Seal 1

10 * O-Ring 1

11 * U-Ring 1

12 Primary Cylinder Nut 1

13 * O-Ring 1

14 Primary Ram 1

15 Circlip 1

16 Cap 1

17 Bolt 1

18 * O-Ring 1

19 Cylinder Head Support 1

20 * Cylinder Pad 2

21 Reservoir 1

22 Pin 1

23 Clip 4

24 Handle 1

25 Handle Grip 1

26 Bleeding Screw 1

27 Sealing Pad 1

28 Plug 1

29 Cylinder 1

30 * Ram Pad 1

31 Washer 2

32 Clip 2

33 Pin 2

34 Leg Assembly 2

35 RS63505R31BK Non-Locking Casters (Black) 2

36 ** Washer 4

37 ** Spring Washer 4

38 ** Hex Bolt 4

39 **RS10038BK Hex Nut (Black) 4

40 **RS10039BK Spring Washer (Black) 4

41 RS63505R37BK Locking Casters (Black) 2

42 Pump Base 1

43 Screw 1

44 Spring Washer 1

45 U-Shape Locking Pin 1

46 Release Pedal 1

47 Pin 1

48 RS10047BK Pumping Pedal (Black) 1

49 RS10048 Circlip 2

50 RS10049BK Pin (Black) 1

51 RS10050BK Connecting Rod (Black) 1

52 RS10051BK Hex Bolt (Black) 2

53 RS10052BK Bushing (Black) 2

54 RS63505R50BK Release Rod (Black) 1

55 * O-Ring 1

56 * Ball 1

57 Flat Washer 4

58 RS63505R51 Saddle Assembly - Red 1

59 RS779301BK Complete Hydraulic Assembly (Black) 1

S01 ** Carriage Bolt 4

S02 Finger 4

S03 Saddle Plate 1

S04 ** Washer 4

S05 ** Wing Nut 4

S06 ** Hook 1

S07 ** Hook Seat 1

S08 Wing Nut 1

S09 Nut 2

S10 Bearing 4

S11 Pin 3 1

S12 Circlip 4

* Seal Kit also available as RS100SK

** Hardware Kit available as RS100HK

Also available: RS7793BFPLK Product/Warning Label Kit

Only index numbers identified by Part Number are available separately.

S13 Pin 1 2

S14 Circlip 4

S15 Cotter Pin 2

S16 Adjust Lever 2

S17 Bolt 2

S18 Saddle Bushing 1

S19 Bolt 1

S20 Bracket 1

S21 Bracket 1

S22 Washer 2

S23 Pin 2 1

S24 Washer 1

S25 Nut 1

S26 Nut 1

S27 ** Washer 2

S28 Chain 1

S29 ** Bolt 1

S30 Nut 2

P1 Screw 1

P2 * Ball 1

P3 Nut 1

P4 * O-Ring 1

P5 Pump Core Pin Sets 1

P6 Dust Cover 1

P7 Dust Cover 1

P8 Big Piston 1

P9 * O-Ring 1

P10 * Washer 1

P11 Spring 1

P12 Small Piston 1

P13 * Washer 1

P14 * O-Ring 1

P15 * Washer 1

P16 Base 1

P17 * Circlip 1

P18 * O-Ring 1

P19 * Copper Pad 1

P20 * Ball 1

P21 RS100P22 Release Valve (Black) 1

P22 * O-Ring 2

P23 Spring 1

P24 Ball 6

P25 Screw 4

P26 Ball 2

P27 Steel Ball Set 1

P28 Spring 1

P29 Screw 1

P30 Spring 2

P31 Washer 3

P32 Screw 3

P33 Spring 1

P34 Spring 1

P35 * O-Ring 1

P36 Push Rod 1

P37 Copper Washer 1

P38 Screw 1

P39 Screw 1

P40 Screw 1

P41 Connector 1

P42 Filter 1

P43 Valve 1

P44 Spring 1

P45 Valve Core 1

P46 Circlip 2

P47 Filter 1

P48 Hydraulic Pump 1

P49 Ball 3

Index No. Part No. Description Qty. Index No. Part No. Description Qty.

FULL UNIT PARTS LIST SADDLE PARTS LIST (CONT.)

POWER UNIT PARTS LIST

SADDLE PARTS LIST
