Sungrow AC011E-01 User Manual

21
figure 2-6 Wall-mounted charger
2.6 Pole-Mounted Installation
It is recommended to install the pole on a solid support surface (such as concrete
or tarmac). If conditions do not permit, install the foundation first, and then install
the mounting pole.
2.6.1 Foundation Installation
The base should be 100 mm above the ground, and the exterior dimensions of the front,
back, left, and right side columns should be greater than 100 mm. Ensure that there are
openings for cables.
User Manual 2 Installation

Sungrow AC011E-01 Specifications

General

Model	AC011E-01
Category	Battery Charger
Output Power	11 kW
Frequency	50/60 Hz
Operating Temperature	-25°C to +60°C
Protection	Overvoltage, Overcurrent, Short Circuit, Over Temperature
Communication	RS485/CAN
