15
Weight
SC2400UD-SC3450UD-MV-US 16000kg
SC4000UD-MV-US 17000kg
SC5000UD-MV-US 18000kg
3.3.3 Ventilation Design
Cooling air comes into the PCS from the top air vent and hot air goes out of the PCS from
the bottom air vent. It’s shown in the figure below.
• Please carry out regular inspections on wire meshes on the air inlets of the top
rain cover and the air outlets at the bottom of the PCS, and perform
maintenance such as cleanup.
• The maintenance interval for the wire mesh should be six months. It is
suggested to shorten the interval to three months or less for the device working
in hash and dusty environments.
System Manual 3 Product Description
