10
Dimensions
The following figure shows the dimensions of the inverter.
figure 2-3 Product Dimensions(in mm)
Weight
Model Dimensions (W*H*D) Weight
SG25/30/33CX-P2
645*575*245 mm
38 kg
SG36/40CX-P2 40 kg
SG50CX-P2 41 kg
SG30CX-P2(For Australia)
600*625*240 mm
35 kg
SG50CX-P2(For Australia) 36 kg
2.3 Symbols on Product
Symbol Explanation
Do not dispose of the inverter together with household waste.
Read the user manual before maintenance!
TÜV mark of conformity.
Regulatory compliance mark.
CE mark of conformity.
EU/EEA Importer.
RoHS labeling
The product complies with the requirements of the applicable
EU directives.
2 Product Description User Manual
