50
Step 4 Tighten the cable gland and the insulator.
Step 5 Check for polarity correctness.
If the PV polarity is reversed, the inverter will be in a fault or alarm state and will
not operate normally.
- - End
5.7.3 Installing PV Connector
Step 1 Ensure that the DC switch is in "OFF" position. Otherwise, manually turn it to "OFF".
5 Electrical Connection User Manual
