Fig.7: Extend the Big Canopy (J) onto the big top by fixing the canopy at four corners of Big Beam (B).
Fig.7-1: Attach the hook rack (H) to panel 2(G2) with the bolt 2 (II).
Fig.8: Insert the connecting piece of panels (G1,G2) into the U-shaped piece of post , then fasten the
panels (G1,G2) to posts (A1,A2,A3,A4) using bolts (I).
Please do not return this product to the store. For technical assistance on assembly,
replacement parts, or warranty questions email menards@sunjoygroup.com.
Fig.9: Fix the gazebo to the lawn by using the Stake (FF).
Your grill gazebo is now ready for use.
FF
Φ6X230MM Stake 8PCS
P12412C01001
