Screw Cap into place until tight.
Do not over tighten.
Place Hopper Plate on Head and fix into position.
Locate the unit on a firm place.
The air passage at the bottom and the side of
Motor Housing should be kept free and not blocked.
(Mincing meat)
Cut all foods into pieces so that they fit easily into
Hopper opening.
Plug in, then switch on.
Feed foods into Hopper Plate.
Use Food pusher.
After use, switch off and unplug.
If the minced meat is not discharged smoothly or in
the form of paste, the causes and remedies could be:
Screw Cap is tighten too much thus, the Cutting
Blade does not contact properly with the Cutting
Plate. Readjust it.
The Cutting Plate is blocked. Clean it.
Cutting Blade edges is dull. Grind or replace it.
·
·
·
NOTE:
?
?
?
To mince meat
Jamming
When the motor is locked, or when the motor
continues to function but no meat comes out of
Cutting Plate, due to jamming of bone or other
materials that stop the motor, switch off.
Do not switch on.
Turn Switch to REVERSE to clear jamming of bone
or other materials.
Clean the unit. (See “To clean below”)
·
To clean
(Disassembling)
(Cleaning)
Make sure that the motor has stopped completely.
Disconnect the plug from the power outlet.
Screw Cap sides are 3 planes , convenient for
unscrewing. If Screw Cap is too tight, please knock
at the planes with a soft-handle , then Screw Cap will
be unscrewed easily.
Unscrew the Locking Knob, and take out Head (with
Cutting Plate, Cutting Blade and Feed Screw), then
put Head mouth downward in order to take out
Cutting Plate, Cutting Blade and Feed Screw.
Remove meat, etc.
Wash each part in warm soapy water.
A bleaching solution containing chlorine will
discolor aluminum surfaces.
Thinners and benzines will crack or change the
color of the unit.
A little salad oil on after washing and drying will
keep them lubricated.
Care is need when handing cutting blade during
cleaning.
Don’t use a perforated disc with holes of 8mm
diameter or smallest with unless an additional
protective hood is provided at the discharge outlet.
8
·
·
≥
· Do not immerse Motor Housing in water, but only
wipe it with a damp cloth.
~
Speed of blade 140r/min
Motor Input Power 550W
Power supply Local Supply 120V 60Hz
Dimensions/CTN 52 25 32
Gross Weight kg
Manufacturer:
Guangzhou Sunmile Electric appliance Manufacture
Corp.,Ltd.
Address:
Yunpu Industrial Park, Luogang District Guangzhou
City, Guangdong, P.R.China.
12.3
XXcm
Technical Specifications
