SPECIFICATIONS
Product Release No.: PR 344 (This is not a model number)
Part Number: 120V Version : 21-3303
240V Aust : 21-3333
230V UK : 21-3343
230V : 21-3363
100V : 21-3373
Input impedance: 1 MΩ
Tubes: Four 6L6GC Tubes p/n 053980
Two 12AX7A Tubes p/n 023572
Four 12AX7WA Tubes p/n 013341
Power output: 120 Watts RMS Arena
29 Watts RMS Club
1 kHz sine wave into 8Ω @ 5% THD Presence @ "1"
Power Requirements: 120V: 120 VAC 60 Hz, 360W
240V: 240 VAC 50 Hz, 360W
230V: 230 VAC 50 Hz, 360W
100V: 100 VAC 50/60 Hz, 360W
Speaker: Designed for use with Sunn 412 Loudspeaker Enclosures
Fuse: T4A 250V fuse for 100V and 120V versions
T2A 250V fuse for 230V and 240V versions
Footswitch: 2 Button Footswitch p/n 053584
(Controls Channel & Effects Loop Select)
Dimensions: Height: 10.2" (25.9 cm)
Width: 24.5" (62.2 cm)
Depth: 11.6" (29.5 cm)
Weight: 45 lbs. (20.4 kg)
Product specifications are subject to change without notice
PARTS LIST
NOTE: SHADED ITEMS ARE FOR REFERENCE ONLY
MAIN
PRINTED CIRCUIT BOARD ASSEMBLY
QTY PART # DESCRIPTION REFERENCE DESIGNATION
2 051660 BRACKET R/A PC MT #6-32 BK1 BK2
1 038690 CAP AE AX 1.0uF 100V C17
2 028953 CAP AE AX 100uF 350V +50% -10% C47 C48
2 038692 CAP AE AX 10uF 35V C35 C38
3 024819 CAP AE AX 22uF 500V C49 C52 C53
1 038693 CAP AE AX 47uF 16V C1
2 024820 CAP AE AX 47uF 350V C50 C51
2 041589 CAP AE AX 47uF 500V C54 C55
2 028494 CAP AE RDL 1000uF 35V 20% C60 C61
2 031040 CAP AE RDL 100uF 100V 20% C56 C57
2 028482 CAP AE RDL 220uF 50V 20% C58 C59
2 036954 CAP AE RDL 22uF 63V 20% C62 C63
3 051458 CAP CD 470pF 500V 10% C3 C8 C18
1 011435 CAP CD 680pF 1000V 10% C16
2 025951 CAP CD 750pF 1000V 10% C13 C15
1 025995 CAP CD 8200pF 1KV 20% C46
5 027272 CAP MPF .047uF 63V C21 C33 C37 C32 C36
1 027280 CAP MPF .15uF 63V C34
1 027286 CAP MPF .47uF 63V C31
1 024823 CAP MPF RDL .01mF 400V 10% C22
6 024833 CAP MPF RDL .022uF 400V 10% C9 C10 C12 C19 C20 C40
4 024845 CAP MPF RDL .047uF 400V 10% C2 C14 C24 C23
2 024846 CAP MPF RDL .047uF 630V 10% C44 C45
2 024853 CAP MPF RDL .1uF 250V 10% C42 C43
1 037666 CAP PPF .001uF 400V 10% C5
1 026202 CAP PPF .0022uF 600V C4
2 025962 CAP PPF .0047uF 400V C6 C41
2 033477 CAP RF 63V .68uF 10% C7 C11
2 041507 CONTROL SNAPIN 1M 10A R6 R15
2 047540 CONTROL SNAPIN 250K 15A R37 R18
3 037597 CONTROL SNAPIN 250K 30A R14 R36 R40
1 047031 CONTROL SNAPIN 25K 30C TAPER R110
2 041510 CONTROL SNAPIN 25K B R16 R38
2 026133 CONTROL TRIM 25K LIN R141 R139
