M4 Allen Wrench
(x1)
M6x10
(x8)
B
1
1.Slide leg columns into place and attach with 8 M6x10 screws.
2.Match inside holes first and lightly tighten at this point.
A
M4 Allen Wrench
(x1)
2
1. Insert Cantilevers on each end, lifting the leg a bit, if needed, to ease into a flush fit. Tab
into place (fit is snug).
2. Using 4 M6x14 screws, tighten all 4 holes lightly. Once level, go back through and
tighten each screw completely.
To Next Page
