IIPERATIlIN
POWER SOURCES:
(Optional)
(10)
Your
Sunpak
Auto
455
Pro-System may
be
used with
six
different
power
sources.
Each
power
source
has
specific
advantages;
select
the
power
source
for
your photographic
needs.
1. Six
alkaline AA batteries
(1OA)
2. Six
rechargeable nickel-cadmium
AA
batteries
(108)
3.
Rechargeable, nickel-cadmium
Battery cluster CL-2
(10C1
4.
The
Sunpak
Multi-Voltage
AC Adapter
(10D)
5.
The
Sunpak
Powerpak
for
510
V Battery
(10E)
6.
The
Sunpak
510
V rechargeable
battery
pak
NC510
(10F)
TO INSTALL
BATTERIES:
1.
Open the
battery
door as illustrated and
remove
battery
holder.
(9)
2. Install batteries
as
illustrated
in the
holder.
Be
sure
to
observe correct
polarity
or
you
may
cause
damage to
you
r
Auto 455 .
[1
1
]
3.
Replace
Battery
Holder
in
your
Auto
455. Extra
Battery
Holders
may
be
purchased
for
time
when rapid replace-
ment
of batteries ls
necessary.
(12)
Note: The Battery
Holder
has
been
designed
to
fit
your
Auto
455
so
as to assure
proper
use, Do
not force
since
it
will
f
it
in
only
the
proper position.
Al
kaline or Nickel-Cadmium Batteries?
The major
advantage
of
alkaline
batteries
is that
they
provide
more flashes
per
set.
While nickel-cadmium batteries
wilr
provide
fewer
flashes
per
set,
they will recycle
your
Auto 455
sl
ightly
faster
and
can
be
recharged hundreds
of
times
for
more
economical
operation over the long run.
Using Multi-Voltage
AC Adapter AD-26
or
Sunpak
Powerpak
for
510
V Battery
1.
For
AC
operation,
be
sure to
check that the
voltage
selector
on
your
Multi-Voltage
AC
adapter
is set
to
the
appropriate voltage.
Your
AC Adapter
has
been
factory
set
for
120
V,
the
U.S.
standard.
For
use in other
coun.
tries
where 100 V,
22OV and
24O
V
are standard,
you
may
adjust
the
setting
as
illustrated.
Remove
the
small
Phillips
head
screw
located next
to
voltage
window
and
rotate the
selector
switch
with
a
screw
driver
to
the
proper
voltage
setting.
After
the
voltage
setting
has
been
made,
the
screw
must
be
reinstalled
to
prevent
accidental
movement
of
the selector
switch.
(13)
2.
Plug
into the
AC/High Voltage
socket
on the
flash
and
into standard
wall
outlet
as
illustrated.
The
AC
Adapter
supplies
virtually unlimited
flashes
and is
ideal
for
indoor
use.
(14)
Note: lf
the Multi-Voltage
AC Adapter is incorrectly
set,
the
adapter will
not
function
properly
and
may
damage
your
Auto
455.
3.
When
you
use
the
optional
accessory Sunpak
Powerpak
for
510
V Battery, refer to
the
instructions
supplied
with that
unit.
Plug
into the Auto
455
in
the
same
manner
as
you
would
with
the
Multi-Voltage
AC
Adapter.
The
Sunpak
Powerpak
for
510
V Battery
allows extreme-
ly rapid
recycle
times and
the
greatest
number of flashes
from
any
portable
power
source.
(15)
MOUNTING
FLASH
ON
CAMERA:
Your
flash
unit has
a
quick-release
mounting
clamp
attached
to the
f
lash
grip
(handle).
This
clamp accepts
a snap-in
bracket;
your
camera
is
secured to the bracket.
As the
bracket
may
be
removed
from
the
clamp with
a one-touch
action,
set-up and disassembly of
your
equipment
is
quick
and
positive.
1. Turn Locking
Button on clamp
counterclockwise.
(16)
2.
Press
Locking Button
f
irmly inward, and
hold
in
place.
(17)
3.
Slide
silver
end
of bracket into
center
of clamp.
(18)
4
4.
Release
Locking Button.
The
bracket
is now
attached to
the clamp.
For
ultimate
security,
you
should tighten
the
locking
screw
by
turning
it
fully
clockwise.
(19)
5.
Press
the Camera
Retaining
Screw through
opening
at
end
slot
on
bracket, and
turn
screw
clockwise
firmly
until
threaded
portion
of
screw
passes
above
bracket
slot.
Center the
camera retaining
screw
under
your
camera's tripod
socket, and
tighten securely.
(20)
6. Connect
the
PC
cord
to the
flash
sync
outlet
(on
the
side
of
the
f lash)
and
camera's
flash
outlet
as shown.
(21)
*
lf the camera
has
separate
flash
terminals
marked
"M"
and
"X",
attach
the
Sunpak
cord to the
"X"
terminal.
*
lf the
camera
has
a
switch
(usuallV
around
the lens
barrel
marked "M"
and
"X"
set
the
switch
to the
"X"
posit
ion.
7. Set
shutter
speed
to the
fastest
speed
usable
for
electronic
flash
with
your
camera,
provided
that
speed
does not
exceed
1/450th second.
O n
single-lens
ref lex cameras
with
focal-plane
shutters,
this
speed
is usually 1/60th
or
1l125th;
cameras
with
in-the-lens shutters
usually
allow
synchronization
at
speeds
up to the
maximum
of 1/45Oth.
Do not
set shutter
to
a
speed
faster
than
1i45Oth
second,
as
this
may
cause
under-exposure when
the
flash
is
used at
maximum
power. (lf
shutter
has
a
switch
marked "M"
and
"X",
place
at
"X"
position.)
(22)
*
Note:
Should
you
desire to
mount
the
flash on the right
side
of
your
camera,
a( raise or lower the
flash handle
within the clamp,
this may be done by loosening the
two
Philips-head
screws
inside
the
encircling
ring
of the
clamp.
(23)
Then
reposition
the encircling ring
as
desired.
Be
sure
to tighten
the
screws again
fully
for maximum
stability and
correct
lighting
angle.
AUT(IMATIC
llPERATItlN
The
sensitive Silicon
Transistor of
your
455
Sensor
measures
the
light ref lected
by
your
subject
and automatical-
ly controls the
f
lash du ration
to
assure correct exposu re
within
a wide range
of
distances.
lt's
easy
to
use:
A.
Slide
the ISO
Film
Speed
Scale
till the ISO
of film
in use
is
visible
in the
ISO
speed
window.
(Example:
ISO 100).
(241
B.
For
the
maximum
distance
range
in automatic
operation,
move
the Auto/Manual
Selector Switch to
the
green
"A"
position
so that the
green
"A"
is
visible
in the
Auto/
Manual Mode Window.
A
Green
line and
t12 will
appear.
,
Then set
your
camera
lens opening
(for
ISO
100 film, the
lens openins
is
f
l2l.
(251
Your
flash and lens are now
set
for
correct
exposure
at
any distance
between
2
m
and
22 m17'
and
72'.
C. For
an intermediate
distance range
in
automatic
opera-
'
tion,
move
the
Selector Switch
to the
yellow
"A"
posi-
tion
so
that
the
yellow
line and
I14
appear.
Then
set
the
same
aperture
on
your
camera
(for
ISO
100 film,
the
lens opening is
f/4).
Your
flash
and
lens are
now
set
for
correct exposure
at any
distance
between 1m
and 11
ml
3.3'and 36'.
(26)
D.
For
maximum
depth-of-field
(greatest
sharpness
in
front
of, and
in
back of the
subject),
move
the
Selector
Switch
to the red
"A"
position
so
that the red "4",
red line and
f/B
appear.
Then
set
your
camera
lens
opening
(for
ISO
100
film
the lens
opening
is
f/8).
Your flash
and lens are
now adjusted
for
correct exposure at any
distance be-
tween 0.7
m
and
5.5
m
(2.3
feet
and
18
feet).
(27)
I
I
l
l
I
I
)
