SUNRAY 801005 - Battery Replacement Procedure; Assembly Instructions Overview; Attaching the Solar Battery Compartment

5
CAUTION: DO NOT INSERT END OF UMBRELLA POLE INTO THE GROUND. The solar umbrella
is designed to be used with an umbrella stand (not supplied).
Attach Solar Battery Compartment Assembly
1. (SEE FIGURE 1) Position battery compartment (A)
at top of umbrella (B).
2. Insert connector plug attached to umbrella into
receptacle located on battery compartment.
3. Insert battery compartment stem into top of
umbrella. Turn battery compartment clockwise
to lock and secure.
PARTS LIST
PART # DESCRIPTION QUANTITY
Carefully remove the contents from the package. If any parts are missing do not
attempt to use the product until they have been obtained and correctly installed.
A Battery Compartment 1
B Upper Umbrella Assembly 1
C Lower Umbrella Pole 1
2
ASSEMBLY INSTRUCTIONS
Figure 1
B
B
C
A
A
Mounting
Stem
Connector
Plug
Parts Detail
Battery Replacement
The rechargeable batteries come preinstalled from the factory. The batteries are located inside
the battery compartment
1. (SEE FIGURE 7) Remove battery compartment (A) from top of umbrella, turn counter-
clockwise to unlock and separate.
2. Carefully unplug connector plug from
battery compartment receptacle.
3. Remove both battery compartment covers.
4. Remove and replace old batteries with new
rechargeable batteries of the same rating.
5. Install new batteries in proper direction,
referencing polarity (+/-) markings for correct
placement and replace the compartment covers.
6. Refer to section entitled "Charging
Rechargeable Batteries" to restore solar lights
to full operation.
Figure 7
A
Mounting
Stem
Mounting
Compartment
Cover
Stem
Connector
Plug
Save these Instructions.
