Lockout Feature
Yourthermostathastheabilitytolockoutadjustmentbyotherusers.This
maybeusefulinpubliclocations.Onlytheon/offswitchandtheGFCItest
buttonwillthenoperate.
1.Pressthedownandupbuttonatthesametimeandholdfor1second.
LOCKwillshowonthedisplay.
2. Tocancelthislockout,thedownandupbuttonmustbepressedandheld
for1second.Thethermostatwillreturntothenormaloperatingmode.
Test the GFCI
ThereisaGFCI(GroundFaultCircuitInterrupter)insidethethermostat.It
isdesignedtohelpprotectpeoplefrompossibleelectricalshockiftheoor
warmingsystemhasbeendamaged.
TomakesuretheGFCIisoperating,testitafteritisinstalledandonceeach
month:
1.MakesurethethermostatisHEATING.Youmayneedtoincreasethe
setpointtemporarily.
2. PresstheGFCITestbuttononthesideofthethermostat.GFCI TRIP
shouldshowonthedisplayandaredlightwillshownexttotheGFCITest
button.Youshouldalsohearaclick,indicatingpowerhasbeenremoved
fromtheoorwarmingsystem.Ifanyoftheseindicatorsfail,turnoffthe
thermostatandreplaceit.Donotcontinuetouse.
3. ToresettheGFCI,slidetheOn/Offswitchoffandbackon.Ifthe
GFCIdoesnotreset,turnthethermostatoffandgotosection6
“Troubleshooting” forhelp.
Limited Warranty
WattsRadiant,Inc.warrantsthisthermostatcontrolandsensor(theproduct)
tobefreefromdefectsinmaterialandworkmanshipforaperiodoftwo(2)
yearsfromthedateoforiginalpurchasefromauthorizeddealers.During
thisperiod,WattsRadiant,Inc.willreplacetheproductorrefundtheoriginal
costoftheproductatWattsRadiant’soption,withoutcharge,iftheproduct
isprovendefectiveinnormaluse.Pleasereturnthethermostattoyour
distributortobeginthewarrantyprocess.
Thislimitedwarrantydoesnotcovershippingcosts.Nordoesitcovera
productsubjectedtomisuseoraccidentaldamage.Thiswarrantydoesnot
coverthecostofinstallation,diagnosis,removalorreinstallation,orany
materialcostsorlossofuse.
Thislimitedwarrantyisinlieuofallotherwarranties,obligations,orliabilities
expressedorimpliedbythecompany.InnoeventshallWattsRadiant,Inc.
beliableforconsequentialorincidentaldamagesresultingfrominstallation
ofthisproduct.Somestatesorprovincesdonotallowlimitationsonhow
longanimpliedwarrantylasts,ortheexclusionorlimitationofincidentalor
consequentialdamages,sotheaboveexclusionsorlimitationsmaynotapply
toyou.Thiswarrantygivesyouspeciclegalrightsandyoumayalsohave
otherrightsthatvaryfromstatetostate.
5. Operation
Controlling the Temperature
Yourthermostathasseveralwaystocontrolyouroorwarmingsystem.It
isfactorysettooperateintheprogramscheduleselectedbutthiscanbe
overriddentomeetyourneeds.
Program Schedule
Thethermostatwilloperatenormallyintheprogramscheduleselected.
Whenheatiscalledfor,HEATINGwillshowonthedisplayand
fullpowerissuppliedtotheoorwarmingsystem.Thisalso
signalstoturnonanySunStatRelaysthatmaybeconnectedto
yourthermostat.
7. Specications
PowerSupply 120/240VAC,50/60Hz
MaximumLoad 15amps,resistive
MaximumPower 1800wattsat120VAC
3600wattsat240VAC
GFCI ClassA(5milliamptrip)
DisplayRange 32°Fto140°F(0°Cto60°C)
SettingRange 40°Fto99°F(4°Cto37°C)
Accuracy ±0.9°F(0.5°C)
StorageTemp 0°Fto120°F(0°Cto49°C)
Sensor Thermistor,10kNTC,double-insulated
Memory Programmingretainedindenitely
Currenttimeanddaywillneedre-set
ifpowerislostmorethan30minutes.
ETLListing ControlNo.3037530
ConformstoUL873,UL943,CSAC22.2No.
24,andCAN/CSAC22.2No.144
6. Troubleshooting
Problem Solution
Thermostatworks
butnoheatfromthe
system.
1.Checkwiringconnections.
2.IfGFCIistripped,resetthermostatwithon/offswitch.
3.Checkresistancesonoorwarmingsystem.See
manualforsystem.
Nodisplay.
1.Checkwiringconnections.
2.Checkcircuitbreakerorotherprotection“upstream”of
thermostat.
GFCIistripped.
1.Checkwiringconnections.
2.Resetthermostatbyswitchingoff/on.
3.Checkresistancesonoorwarmingsystem.See
manualforsystem.
Heatingoccursat
wrongtimes.
1.Checkthatthecurrenttimeandscheduletimesare
properlysettoAMorPM.
2.OnuninsulatedconcreteSmartStartmaystartheating
veryearly.Youmayturnthisfeatureoffifnotdesired.
Er1(onlyatstartup)
Floorsensornotcorrecttypeoroutofrange.Checkoor
sensorresistance.
Er2
Floorsensorshort-circuited.Turnoffpoweratbreakerand
replacesensor.OrResetFactoryDefaults(section4).
Er3
Floorsensornotattachedandthermostatinoorsense
mode.Turnoffpoweratbreakerandattachsensor.Or
ResetFactoryDefaults(section4).
Er4orEr5
Internalairsensorisfaulty.Replacethermostator
operateinoorsensemode.
Er6
Internaltemperatureoverlimit.Makesuresunlightis
notdirectedatthethermostatorotherheatsourcein
proximity.Otherwise,Turnoffpoweratbreakerand
contactfactory.
Er7
“End-of-life”indication.GFCIwillnolongerfunction
correctlyorsafely.Resetthecircuitbreakerorreplace
thermostat.
Temporarily Overriding the Temperature
Youcantemporarilyadjustthetemperaturesetpointasfollows.Thiswillhold
untilthenextscheduledprogramtime:
1.Pressthedownoruparrowbuttonandholdfor1secondtoadjustthe
setpointtemperature.
2. Wait5secondsandthethermostatwillreturntothenormaloperating
mode,savingyouradjustment.
3. Tocancelthistemporaryoverrideandreturntothenormal
scheduletemperature,presstheHOLD/RETURNbuttonbriey.
Hold a Selected Temperature
Youcanholdthecurrentsetpointtemperatureindenitely,
especiallyusefulwhenyouareonvacation.
1.PresstheHOLD/RETURNbuttonandholdfor1second.HOLDwillshowon
thedisplayandthesetpointtemperatureshownwillbemaintaineduntilyou
cancelthishold.
2. Tocancelthishold,presstheHOLD/RETURNbuttonandholdfor1second.
HOLDwilldisappearfromthedisplay.
3. PressHold/Returnbrieyandthethermostatwillreturntothe
normalscheduletemperature.
Setback
YoucanusetheSetbackbuttontooverridethecurrentsetpoint
temperature.Thisisespeciallyusefulifyouhaveanalternate
temperatureyourepeatedlyselectwhenyouareaway.
1.PresstheSETBACKbuttonbriey.SETBACKwillshowonthedisplayand
itstemperature.Thissetpointwillholduntilthenextscheduledprogramtime.
2. ToholdthisSetbacktemperatureindenitely,presstheHOLD/RETURN
buttonandholdfor1second.Tocancelthishold,presstheHOLD/RETURN
buttonagainandholdfor1second.
3. TocancelthisSetbacktemperatureandreturntothenormalschedule
temperature,presstheSETBACKbuttonbriey.
To change the temperature stored in the SETBACK button:
1.PresstheSETBACKbuttonandholdfor1second.SETBACKwillshowon
thedisplayanditstemperatureshouldbeblinking.
2. Pressthedownorupbuttontoadjustthetemperature.
3. PresstheHOLD/RETURNbuttonorwait5secondsandthethermostatwill
returntothenormaloperatingmode,savingyouradjustment.
Remote Control Override
IfyourthermostatwasinstalledwithRemoteControlinputfromahome
automationsystem(seesection2 “Installation”),thiswilloverridethe
thermostatwhentheremotecontrolsystemclosesitsoutputswitchorrelay.
SETBACKandHOLDwillshowonthedisplayanditwilloperateintheSetback
temperatureindenitely.Tocancelthis,theRemoteControlswitchorrelay
mustbeopened.
