SUNVILLA 2127220 - Page 3

3/10
PART NO. PICTURE QTYDESCRIPTION
A
Plastic Base Cover
1
B Plastic Base
4
C
Base
1
4
Base Bolt
Corner Piece
1
Wrench
AA
BB
CC
Umbrella Parts & Hardware Kit List
Umbrella Base
NOTE: This base is designed for only the item numbers
A
4
B
C
AA
BB
listed in the beginning of the instructions.
D
Frame and Canopy
1
DD
Crank
1
EE
M10 x 20 Bolt
PART NO. PICTURE QTYDESCRIPTION
8mm Hex Wrench
Φ10 Washer
FF
GG
HH
II
JJ
KK
4
4
1
6mm Hex Wrench
2.5mm Hex Wrench
M8 x 16 Bolt
Φ8 Washer
2
2
1
1
Base Tube
Packed with umbrella
1
E
Assembled with Part D
Assembled with Part D
