SUNVILLA 2127623 - Assembly Steps; Step 1: Remove Top Cap; Step 2: Install Solar Panel; Step 3: Attach Bottom Pole

Step 1
Remove the small cap from the top of the umbrella by rotating it counter
clockwise. This cap can be kept to reuse in the future.
Step 2
Insert the Solar Panel (A) into the top of the umbrella, and rotate 90 degrees
to lock it into place.
B
A
Assembly
5
Step 3
Insert Bottom Pole (C) into the Upper Frame and lock into place.
Press
C
Press
