3
2.2 Zuordnung Kabelfarbe/ Klemmen
BB IN
FOX-D1
Rot
Blau
Schwarz
Sicherung: 0,5 A, Feinsicherung
5 x 20 mm, flink
Für den mechanischen Einbau muß ein Ausschnitt von
56 mm x 84 mm geschnitten werden.
Minimale Einbautiefe: 50 mm
Hinweis für FOX-D1/E:
