EN
NOSE GUARD — Z — Figure 17/18
Removal — Figure 17
The nose cover is snapped into place between the cap and the inner
lining of the chin guard. To remove it, all you have to do is pull it
upwards.
Assembly — Figure 18
Place the nose cover in the middle of the visor’s opening, inserting
the tabs between the cap and the chin guard. Press with force on the
nose cover where the tabs are located until the lower edge of the
nose cover is fully adherent to the edge of the cap.
If this doesn’t happen and the nose guard does not adhere to the
edge of the shell or is not positioned correctly, do not use the
helmet and contact authorized Suomy personnel only.
HEADPHONE PREDISPOSITION - Figura 19/20
HEADPHONE
PREDISPOSITION
REMOVE
COVER
FIGURE 17
FIGURE 19
FIGURE 18
FIGURE 20
Z
32
