AUTO IRIS LENS
CONNECTOR
2EA
C RING
1EA
Instruction Manual
1EA
FOOT
1EA
SCREW
2EA
8. Package
4. Key Features
5. Specifications
6. Cable Connection
7. Camera Connection
• 1/3” SONY Progressive Scan Color CMOS Sensor
• 1080(1920x1080)@30fps
• TV out(BNC) with NTSC/PAL selectable
• Dual Output-Megapixel HD CCTV(BNC) & SD CCTV(BNC) Out
• Defog(Visibility enhancement on the low contrast scene)
• High resolution digital zoom (x64)
• PIP(Full Image / Zoom Image)
• Flicker suppression
• No noise, ghosting effect with DNR
• Dual Power(AC 24V / DC 12V)
Camera
1EA
*C & CS Mount Lens
3. Dimension
OSD Control Board D&N RS485(HD-F750)
Sensor
Total Pixels
Effective Pixels
Scanning System
S/N Ratio
Minimum Illumination
White Balance
Video Output
Electronics Shutter Speed
OSD
BLC
AGC
DNR
Day & Night
Defog
PIP / Digital Zoom
Privacy
Lens
Power Supply
Power Counsumption
Operating Temperature
Storage Temperature
Dimension
Weight
MODEL
BLK-HDC20HDMI
1/3" SONY CMOS
2000(H) X 1121(V)
1984(H) X 1105(V)
Progressive Scan
More than 50dB
0.02Lux(Sens-up x60)
ATW / AWC >SET / Manual >SET
HD-SDI / CVBS : 1.0 Vp-p 75ohm
Auto / Manual Selectable
Built-in
BLC / HSBLC / Off Selectable
High / Middle / Low
2DNR / 3DNR
Auto / BW / Color / EXT
High / Middle / Low / Off Selectable
On(x2~x64) / Off
On(8 Programmable Zone) / Off
C & CS Mount (Lens Option)
Dual Voltage
120mA
0°C~60°C
-10°C~70°C
58mm(W) * 52mm(H) * 123mm(D)
350g
