Problem Possible Solutions
Interference in video
• Adjust the orientation of the antennas on the Transmitter and Receiver
modules.
• Move the equipment away from devices that emit high radiation, such as
microwave ovens, wireless phones, etc.
Specications - system
Item Specication
Transmission channels 4 channels, auto selected
Video bit rate Up to 12 Mbps
ID codes Up to 4 M
Video resolution 720 x 480 @ 30 fps (NTSC)
Image processor MPEG4 encoding / decoding
Operational range 300 ft (line of sight)
Remote control range 300 ft (line of sight)
Specications - Transmitter module
Item Specication
Operating frequency 2.4000 GHz – 2.4835 GHz
Transmit power 100 mW (maximum)
Modulation 16 QAM / QPSK / BPSK
Video input level 1 ± 0.2 Vp-p @ 75
Audio input level 1 ± 0.2 Vp-p @ 600
Antenna Omnidirectional
Power consumption 1.9 W
Power adapter 12 VDC / 1A
Dimensions (L x W x H) 4.53” x 3.15” x .98” (115 mm x 80 mm x 25 mm)
Operating Temperature
14°F ~ 122° F 10°C ~ 50°C
Weight 3.88 oz (110 g)
Specications - Receiver module
Item Specication
Operating frequency 2.4000 GHz – 2.4835 GHz
Receiver sensitivity -80 dBm minimum
Video output level 1 ± 0.2 Vp-p @ 75
Audio output level 1 ± 0.2 Vp-p @ 600
Antenna Omnidirectional
Power consumption 1.9 W
Power adapter 12 VDC / 1A
Dimensions (L x W x H) 4.53” x 3.15” x .98” (115 mm x 80 mm x 25 mm)
Operating Temperature
14°F ~ 122° F 10°C ~ 50°C
Weight 3.81 oz (108 g)
For product support, please contact your distributor.
