EXPLODED AND PARTS LIST
AC
Part No.
1
2
3
4
5
6
7
8
9
10
11
Description
Strap
Barrel cover
Barrel body
Battery holder
Battery cover
Screw
Ventilation pipe
Connector
Rubber plug
Screw
Fan back cover
Q’ty
1
1
1
1
1
10
1
1
3
8
1
Part No.
12
13
14
15
16
17
18
19
20
21
22
Description
Fan seal
AC fan assembly
Fan housing
Spring
Plug wire assembly
Line card
Screw
Base
Steel ball
Line card
Sprinkler components
Q’ty
1
1
1
2
1
1
2
1
2
1
1
