Parts Diagram and Replacement Parts for the Pizza Oven
Reference
Number
PO-18 Part
Number
PO-22 Part
Number Description
1 PO1-1 PO2-1 Top and Middle Heating element
2 Top Heating Element Box
3 PO1-3 PO2-3 Ceramic Hearth Baking Shelf
4 PO1-4 PO2-4 Bottom Heating Element
5 PO1-5 PO2-5 Door
7 PO-7 PO-7 Temperature Indicator - Orange
8 PO-8 PO-8 Timer
9 PO-9 PO-9 EGO Thermostat
10 Control Panel
11 Screw- S/S
12 PO-12 PO-12 Timer Knob and Scale Plate
13 PO-13 PO-13 Thermostat Knob and Scale Plate
14 Screw- S/S
16 Thermostat Wire Support
17 Thermostat Probe Rack
19 Screw- Zinc Plated
20 Oven Body
21 Back Plate
23 PO-23 PO-23 Power Cord and Strain Releif
24 PO-24 PO-24 Terminal
25 PO-25 PO-25 Gasket
26 Screw- Zinc Plated
27 PO-27 PO-27 Steel Foot
PZO-22-1PZO-18-1
