Superior IO-360 SERIES User Manual

Model Specification Data
IO-360 Series Engine
14 Appendix B • IO-360 Model
© March 2004 Superior Air Parts Inc. Specification Data
Figure 13 • Fuel Mixture Curve-65% Power
Economy Cruise Fuel Mixture Curve
Superior Vantage IO-360 Series
24 in-Hg x 2400 RPM
-250
-200
-150
-100
-50
0
Below Peak EGT (°F)
-75
-50
-25
0
Below Peak CHT (°F)
80
90
100
110
120
Corrected Power (Hp)
0.40
0.45
0.50
0.55
0.60
0.65
0.70
42 44 46 48 50 52 54 56 58 60 62 64 66 68 70 72 74
BSFC (Lb/Hp-hr)
Fuel Flow (Lb/Hr)
