Superior IO-360 SERIES User Manual

Model Specification Data
O-360 Series Engine
7 Appendix A • O-360 Model
© March 2004 Superior Air Parts Inc. Specification Data
Figure 6 • Carburetor Installation Drawing
RADIAL CLEARANCE MUST BE
MAINTAINED AS SHOWN AT FULL
RICH POSITION OF LEVER
3.30
.255
.250
THROTTLE CLOSED
2.70
ALLOWABLE
LINEAR TRAVEL
.66
17°
2.296
2.136
.172
.162
R.42
IDLE CUT OFF
R1.75
43.30°
76.30°
FUEL PRESSURE CONNECTION
.125−27NPSF
FUEL INLET .250−18NPSF
1.50
2.72
2.38
THROTTLE
OPEN
83°
REF
R1.69
FULL RICH
DIA
Fuel Metering System
Carburetor
