Trailer Valet

Parts list

1

2

3

4

5

6

7

8

9

9

10

11

12

13

14

15

16

17

19

18

20

21

22

23

24

1 Axle yoke assembly

2 Acme jack assembly

3 Jack crank

4 Drive handle

5 Brake handle

6 Brake cap assembly

7 Left bearing housing

8 Right bearing housing

9 Gear cover

10 Low gear driveshaft

11 High gear driveshaft

12 Drive shaft bearing

13 Brake engagement lever

14 Axle bearing

15 Drive wheel

16 Follow wheel

17 Axle gear

18 Low gear chain

19 High gear chain

20 Trailer mount bracket

21 Trailer mount clamp

22 Stow pin

23 Rotation pin

24 Tire
