Sutron Corporation 8310 & 7310 Users Manual 8800-1125Rev. 2.7 (BETA) 4/16/2014 pg. 119
Individual
Individual values logged for the output
since the last transmission will be
transmitted.
DataInterval
the time interval between readings from
the 8310 log
DataTime
the time at which to begin extracting data
from the log in order to build a message
NumVals
No. of data items for each parameter taken
from 8310 log and encoded in each
self-timed transmission
Sequence
Sequence determines the order of this
output in the transmission message.
Exclude
Do not transmit this output.
Station Setup/Communications/COMx SATLINK/Random Settings
A typical Random Settings menu is shown below followed by a description of all the items.
Random Settings
Enabled No
NormalRate 12:00:00
AlarmRate 01:00:00
BurstRate 00:01:00
NumAttempts 3
Channel 151
Type 100 bps
Format Bin Int
NumVals 1
GroupLabel B2
AppendLatLon No
Select outputs >
End Random Settings
Enable
This box must be checked for the system to make random transmissions. This field is sent to the
Satlink to configure the transmitter and uses the field to control its own scheduling.
NormalRate
The “Normal Rate” property defines how often random transmissions will be made, when the
unit is not in alarm. The rate is specified in HH:MM:SS.
AlarmRate
The “Alarm Rate” property defines how often random transmissions will be made when the unit
is in alarm, following burst transmission(s). The rate is specified in HH:MM:SS.
BurstRate
The “Burst Rate” property defines how often the “# Burst” random transmissions will be made.
These burst transmissions occur when the unit first goes into alarm. The rate is specified in
