M1.O1*: RelHumid 1.00 G
M1.O2*: RelHumidMin 2.50 G
M1.O3*: RelHumidMax 2.50 G
M1.O4*: RelHumidCnt 60.00 G
M1.O5*: RelHumidSTD 0.00 G
M2.O1: AirTemp 0.00 G
M3.O1: WaterLevel 0.00 B
M4.O1: Stage 1.00 G
M4.O2: StageMin 1.00 G
M4.O3: StageMax 1.00 G
M4.O4: StageCnt 900.00 G
M4.O5: StageSTD 0.00 G
M5.O1*: TipBkt -999.90 G
M6.O1: WindMnSpdSclr 0.00 G
M6.O2: WindMnMagUnit 1.00 G
M6.O3: WindMnMagWind 0.00 G
M6.O4: WindMnDirUnit 3.24 G
M6.O5: WindMnDirWind 270.00 G
M6.O6: WindSTDSpdScl 0.00 G
M6.O7: WindSTDDirUni 0.85 G
M6.O8: WindSTDDirWin 2.52 G
RIGHT to edit SETUP
The number in parenthesis is the number of outputs configured in measurements. The
diagnostics/outputs menu allows you to view the last measured value for each output. For
some outputs, you can force a live measurement by pressing SET/ENTER and view data in the
log by pressing RIGHT.
Mx.Ox name curval > viewlog SET/ENT measure (if supported)
Diagnostics/I/O Modules (n)
I/O Modules (3)
DSP1
DIO1
AIO1
Reset module bus
End I/O Modules
RIGHT shows details
The number in parenthesis is the number of I/O modules installed in the 8310. Each 8310 has
at least 3 I/O modules: the display, the analog I/O providing the analog inputs and the digital I/O
providing the digital inputs. The I/O Modules menu displays the name for each of the I/O
modules and provides details when needed.
The following is a typical display of the I/O module information. Note that you don’t see the
“details” of serial number, address, etc, unless RIGHT arrow is pressed.
