Concepts
Connecting sensors is as simple as connecting the wires from the sensor to the terminal strip. As
a standard practice you should test each new application (sensor connections and setup) on the
bench prior to installing it in the field. Then create a complete setup sheet and wiring diagram
that shows where each sensor wires is attached to the 8310. This will take the guesswork out of
connecting the sensors in the field.
-0.1 to 5V with respect to ground, single
ended or differential
0-5 V, + 78 mV (with respect to ground)
+2.5V, + 78 mV ( + input with respect to –
input)
0.002% of 5V typ 0.003% of 78mV typ HiGain
0.03% of 19.5mV typ x128Gain
Limited by A/D resolution
RMS noise typically < 1bit on 78mV scale and
above
Multistage input protection including spark
gaps.
Precision load available for 2 analog
channels. Loop source voltage provided by
switched battery voltage
Intended for tipping bucket, frequency or
discrete inputs (quadrature takes 2 inputs)
8kHz, minimum pulse width 100
microseconds
0-5V (100KOhm pull-up to +5V provided)
+0.07% @200 ms sample interval
+0.03% @500 ms sample interval
+0.01% @1000 ms sample interval
Open collector with 100 ohm current
limiting resistor, 100 mA, 15V max
Switched battery, Switched +5
