Sutron Corporation 8310 & 7310 Users Manual 8800-1125Rev. 2.7 (BETA) 4/16/2014 pg. 25
7310-O
The Display
The 2 line LCD backlit display is a window into the 8310 system. It is in this area that the 8310
displays a variety of messages which are used to set up and test the unit. The display is ON
generally only after pressing a key in the keypad.
The two-line display shows one menu item at a time, using the second line to display additional
information like a value, a hint or help. Users can fully setup the logger using this front panel
interface (except for Basic). The system includes many features that help simplify the use of the
front panel:
The 6-button Keypad
The 6-button keypad ( ) is used to control the 8310.
