Sutron Corporation 8310 & 7310 Users Manual 8800-1125Rev. 2.7 (BETA) 4/16/2014 pg. 53
8310 Menu Reference
Each Menu item in the 8310 is documented in the following sections. First, all the items of the
Main Menu are documented followed by each of the sub menus in alphabetical order. The
items within each menu/sub-menu are listed in alphabetical order based on the front panel
name. Each Menu item is described in a separate section identified by its name and Menu Path.
At the top of each page is a header that contains the menu path for one of the items described
on the page. You can look at this header while turning pages to help you find a particular menu
and item.
The items in a sub-menu are described in sequential order.
The menu path shows all the menus you must use to select a particular item. The Main Menu is
implied in the menu path. The following are some examples menu paths:
Example 1: Station Setup/Measurements/Mx /Mx.Ox
Navigation:
From Main Menu, select Station setup
Then select Measurements
Then select a specific measurement Mx
Then select a specific output Ox
Note: select means to highlight and then press RIGHT
Example 2: Station Setup/Communications/COMx SATLINK/SelfTimed Settings
Navigation:
From Main Menu, select Station setup
Then select Communications
Then select a specific Communications port COMx
Then select a SelfTimed Settings
