Function code Name Default Min. Unit Setting Range
F5-30 Y5 function selection 0 1 0～16
F5-31 Y6 function selection 0 1 0～16
The system output is relay output. There are function items 0～16:
0：No function:
Output terminal hasn’t any function.
1：Run contactor output:
The system outputs the pick-up command of run contactor; control the run contactor’s pick-up
and release.
2：Brake contactor output:
The system outputs
the pick-up command of brake contactor, achieving the output signal of
brake and release control.
3：Lock contactor output:
The system outputs the pick-up command of envelop door contactor, fulfilling pre-opening, door
lock jump out when micro leveling, and release control.
4：Fire arrival land signal feedback:
When in fire state, the system sends out feedback signal to monitor after lift returns to the
fire
land.
5：Front door open:
The corresponding terminal is used for outputting the signal of front door open.
6：Front door close:
The corresponding terminal is used for outputting the signal of front door close.
7：Back door open:
The corresponding terminal is used for outputting the signal of back door open.
8：Back door open:
The corresponding terminal is used for outputting the signal of back door c
lose.
9：Brake, run contactor normal:
The corresponding terminal is used for outputting normal signal of the brake and run contactor.
When the system shows E37, E36, it means the brake and run contactor error and the terminal
don’t output.
10：Failure state:
The corresponding terminal is used for outputting signal when errors occur in 3, 4, and 5 ranks.
The ranks of errors are in chapter 8.
