Technical document –Recharging Box’s User instruction
6
3. Connection
3.1. Connecting to the grid
Connect the 12V
DC
power supply to the power connector of the Recharging Box, as shown in
the figure below.
Fig. 2
3.2 Cashless device connection
Open the rear door and connect the cashless device to the PC via micro USB cable.
Fig. 3
POWER
MICRO
-
USB
PROGRAMMING
CONNECTOR
