5-2
OTHER CONTROLS AND EQUIPMENT
60MK0-14E
Side outlet
68LM502
Move the knob (1) vertically and the dial
(2) horizontally, to adjust the direction of
airflow as desired. When “Open”, air
comes out from the side outlets regardless
of the airflow selector position.
(1)
(2)
Center outlet
74LHT0502
Move the knob (1) vertically or horizontally to adjust the direction of airflow as desired.
(1) (1)
