Svan SHM4700X - Page 8

Minimum bottom ventilation area: 250 mm
2
*
Min.
570
If the appliance is installed under the hob, the minimum
thickness of worktop A is shown below:
≥ 5
35
Native appliance
Native appliance
Without hob
Hob
576
≥5
Cabinet Diagram (Ground Cabinet)
600
Min.
50
600
+2
Min. 590
+8
560
Air vents
≥ 5
35
A
With hob
576
≥5
Hob type
Induction hob 37 mm
worktop A
Full-surface induction hob 47 mm
Gas hob
Electric hob
30 mm
27 mm
5
20
20
Reserve 5 mm for the door panel at the top and
bottom respectively.
Reserve 20 mm for the door panel on the left
and right respectively.
Reserve 20 mm for the door panel in thickness.
EN-5
595
595
20
555
