SV 200A User Manual
SETUP file
Word
number
Name
Comment
0
0x0020
[20, 00=block’s length in the second word]
1
BlockLength
length of the block
2..BlockLen
gth-1
SetupData
saved setup values
Header of the file from the logger
Word
number
Name
Comment
0
0xnn0F
[0F, nn=header’s length]
1
BuffTSec
logger time step - full seconds part
2
BuffTMilisec
logger time step - milliseconds part
3
LowestFreq
the lowest 1/1 OCTAVE or 1/3 OCTAVE frequency (*100 Hz)
4
NOctTer
number of 1/1 OCTAVE or 1/3 OCTAVE results
5
NOctTerTot
number of TOTAL values
6..7
BuffLength
logger length (bytes)
8..9
RecsInBuff
number of records in the logger
10..11
RecsInObserv
number of records in the observation period equal to:
number of records in the logger + number of records not saved
12..13
AudioRecords
number of audio records in the logger
14
MStUnitNumber
monitoring station unit number
(ignored if 0xFFFF)
15
MStUnitType
type of the monitoring station: 205 (SV 205B), 209 (SV 209)
(ignored if 0xFFFF)
16
MStSoftwareVersion
monitoring station software version
(ignored if 0xFFFF)
17..18
MStIntTimeSec
integration period of meteo results in seconds
(ignored if 0xFFFF)
19
MStCalDate
last calibration date
(ignored if 0xFFFF)
…
…
…
Note: The current logger time step in seconds can be obtained from the formulae:
T = BuffTSec + BuffTMillisec / 1000
Contents of the file from the logger
Word number
Name
Comment
0..(BuffLength/2-
1)
result#1, result#2, ... result#(BuffLength/2-1)
METEO data
Word number
Name
Comment
0
0xnn2A
[2A = id, nn = block’s length]
1
BlockLength
block length
2
UnitNumber
unit number
