b
e
g
c
f
a
d
5. CONNECTION AND INSTALLATION
• Connect the web camera to an available USB port.
• This web camera supports Plug
and Play technology. Installation of
the device is automatic after its
connection to USB port.
6. DESCRIPTION
a Snapshot button
b Lenses
c Effects switch button
d Built-in microphone
e Focus
f Hinge
g Mounting clip
Fig. 1. Web camera description
ENG
3
IC-650
User’s Manual
7. TECHNICAL SPECIFICATIONS
Parameter, unit
Sensor type
Resolution, pix
Frame rate, frames/sec
Focus distance, mm
Cable length, m
Value
CMOS
640 × 480
up to 30 fps for 640 × 480
2.8 to infinity
1.5
Notes:
• Technical specifications given in this table are supplemental information
and can not give occasion to claims.
• Technical specifications are subject to change without notice due to im-
provement of SVEN production.
