ENG
5
User Manual
PS-290
PS-295
Fig. 2. Connection diagram
Note. At the subsequent inclusion of both speakers, they will be connected
automatically.
The use in the wired mode (AUX)
•Speaker system can be used as an external device for amplifying any audio source
with a 3.5 mm output mini-jack. To do this, connect a cable 3.5 mini-jack – 3.5 mini-jack
to the audio output AUX h.
TECHNICAL SPECIFICATIONS
Parameter, measurement unit Value
Frequency range, Hz 60-20000
Output power (RMS), W 20 (2 × 10)
Membrane, mm Ø 60
Radius of operation Bluetooth, m up to 10
Battery capacity, mA*h 3000
Power supply USB ⎓ 5 V
Weight, g 900
Dimensions, mm 95 × 240 × 103
Notes:
• Technical specifications given in this table are supplemental information and cannot
give occasion to claims.
• Technical specifications and package contents are subject to change without notice
due to the improvement of SVEN production.
