Sven PS-340 - Wired Mode and Technical Specifications; Use in Wired Mode (AUX); Technical Specifications

ENG
5
User Manual
PS-340
Fig. 2. Connection diagram
The use in the wired mode (AUX)
•Speaker system can be used as an external device for amplifying any audio source
with a 3.5 mm output mini-jack. To do this, connect a cable 3.5 mini-jack – 3.5 mini-jack
to the audio output AUX k.
TECHNICAL SPECIFICATIONS
Parameter, measurement unit Value
Frequency range, Hz 60-20000
Output power (RMS), W 24 (2 × 12)
Speaker diameter, mm Ø 70
Rated current consumption, A 0.43
Battery capacity, mA*h 3600
Power supply USB /
5 V
Weight, g 1800
Dimensions, mm 283 × 124 × 123
Notes:
• Technical specifications given in this table are supplemental information and cannot
give occasion to claims.
• Technical specifications and package contents are subject to change without notice
due to the improvement of SVEN production.
