Fig. 1. Connection diagram
Аudio
sources
4 pin connector
for mobile devices
To earphones
Call acceptance /
Pause button
Microphone
TECHNICAL SPECIFICATIONS
Parameter, measurement unit
Sensitivity, dB
Impedance, Ohm
Frequency range, Hz
Membrane, mm
Connector type
Cable length, m
Weight, g
Value
earphones: 106 ± 3;
microphone: -42 ± 2
16
earphones: 18 – 20,000
microphone: 30 – 16,000
Ø 10
Ø 3.5 mm (4 pin) mini jack
1,2
17
Note. Technical specifications given in this table are supplemental infor-
mation and cannot give occasion to claims. Technical specifications are
subject to change without notice due to the improvement of SVEN produc-
tion.
ENG
2
Technical support is on www.sven.fi.
Multimedia Headphones
with Microphone
CONNECTION AND OPERATION
• Connect the 4 pin connector of the earphones to the audio output jack of
your audio source (phone, smartphone, MP3 player), as shown in Fig. 1
• Adjust the earphones volume level as desired with the volume control of
a sound source.
