Services
46
- Microswitched systems with an internal
water tank, using two pumps and a
solenoid valve arrangement to cover all
water system requirements.
INTERNAL TANK OPERATIONS –
PRESSURE SWITCHED SYSTEM
When an internal water tank is fitted options
exist to supply water to the taps and shower
from either the internal tank or the external
supply.
Before using the water system ensure that
the drain valves both in the hot and cold
circuit and adjacent to the water heater are
in the closed positions (See page 44)
TO USE AN EXTERNAL WATER CARRIER
TO SUPPLY THE TAPS:
- Ensure that the external hose and filter
assembly is connected, and suspended in
the external water container with water
present.
- Close the tank isolation valve on the mid
right of the tank installation, (see diagram
page 44)
- Turn the selector valve to the left of the
tank installation clockwise to connect the
external supply to the water pump.
- Switch the pump switch to the ‘ON’
position on the control panel
If the taps within the caravan are closed, the
pump will run until the correct pressure is
attained within the plumbing. If the water
system is being operated for the first time or
from a drained condition, air in the system
will need to be expelled. Opening the internal
taps in the caravan will allow this to happen,
this should be repeated at the hot and cold
position of each tap / mixer, until water is
flowing freely in all cases.
TO USE THE INTERNAL WATER TANK TO
SUPPLY THE TAPS:
- Check the water level gauge on the control
panel to confirm the water level within the
tank.
- Close the tank isolation valve on the mid
right of the tank installation, (see diagram
page 44).
- Turn the selector valve to the left of the
tank installation anti-clockwise to connect
the supply from the internal tank to the
water pump.
- Switch the pump switch to the ‘ON’
position on the control panel
If the taps are closed within the caravan the
pump will run until the correct pressure is
attained within the plumbing system. If any
of the taps are open water will flow from
those taps as soon as the pump is switched
on, unless the system is being run for the
first time or from a drained condition.
TO FILL THE INTERNAL TANK:
- Ensure that the external hose and filter
assembly is connected, and suspended in
the external water container with water
present.
- Open the tank isolation valve on the mid
right of the tank installation, (see diagram
page 44)
- Turn the selector valve to the left of the tank
installation clockwise to connect the
external supply to the water pump.
- Ensure all of the taps within the caravan are
in their closed positions.
- Switch the pump switch to the ‘ON’
position on the control panel
Water will now be drawn from the external
container by the internal pump and forced
into the internal tank. Water will flow into the
tank until either the external container is
empty, or the internal tank overflows.
Progress can be monitored using the water
level gauge on the control panel.
INTERNAL WATER TANK OPERATIONS –
MICROSWITCHED SYSTEMS (CAMEO)
When an internal water tank is fitted options
exist to supply water to the taps and shower
from either the internal tank or the external
supply. A normally closed solenoid valve is
mounted with the ‘Posiflo’ internal pump on
these models, and is controlled by a switch
